ITI Fitter Mock Test MCQs For Govt Exam

ITI Fitter Mock Test MCQs help the candidates in preparing for the upcoming ITI trade exams. These MCQs have been formed taking guidance from the previous year question papers. Solving the mock test papers help a candidate understand his/her strengths and weaknesses and brush up on the weaker sections.

The ITI Fitter trade is a course with a duration of 2 years. The course is divided into four semesters. After completion of the course, the candidates are given NCVT/SCVT certificates. Finishing the ITI trade courses makes the candidates industry ready.

The ITI courses are vocational courses that focus both on theories and practical skill development. Other trades offered by ITI include electrician, plumber, draughtsman, computer operator, and many more.

This article shares the ITI Fitter mock test MCQs that are crucial in preparing for the exams.

Table of Contents

• ITI Fitter Mock Test MCQs
• ITI Fitter Mock Test MCQs for Fitter Theory 1st Year
• ITI Fitter Mock Test MCQs for Fitter Theory 2nd Year
• ITI Fitter Exam Pattern

ITI Fitter Mock Test MCQs

Mock tests are prepared to allow the candidates to test their knowledge and preparedness for the exam as well as to give them an understanding of the type of questions asked in the exam.

The ITI Fitter mock test MCQs are prepared based on the question papers from previous years. By taking the mock tests, the candidates can not just check their preparation for the exam but also work on their weaknesses.

ITI Fitter Mock Test MCQs for Fitter Theory 1st Year

1. What is the first step of avoiding accidents in the workplace?

(A) Doing things in one’s own way

(B) By observing safety precautions

(C) By wearing Safety Equipment

(D) Doing things with skilled working practice

Ans: B

2. Which fire extinguisher is filled with carbon tetrachloride and BCF?

(A) Dry powder extinguisher

(B) foam extinguisher

(C) Halon extinguisher

(D) carbon dioxide

Ans: C

3. What does A denote in the ABC of first aid?

(A) Arresting

(B) Attention

(C) Airway

(D) Atmosphere

Ans: C

4. Which of the following comes under mechanical occupational hazard?

(A) Unguarded machinery

(B) Unskilled men

(C) Toxic

(D) Noise

Ans: A

5. What class of fire is caused by cloth, paper, fire wood?

(A) Class A fire

(B) Class B fire

(C) Class C fire

(D) Class D fire

Ans: A

6. Which chisel is used in the squaring of materials at the joints and corners?

(A) Diamond point chisel

(B) Flat chisel

(C) Half round nose chisel

(D) Cross cut chisel

Ans: A

7. Which kind of chisel is used in the removal of materials at the corner of the keyways?

(A) Diamond point chisel

(B) Flat chisel

(C) Half round nose chisel

(D) Cross cut chisel

Ans: A

8. Which file is needed for the filling of wood and leather?

(A) Single cut file

(B) Rasp cut file

(C) Bastard file

(D) Hand File

Ans: B

9. Why does a new hacksaw blade become loose after a few strokes?

(A) worn out nut thread

(B) improper saw sets selection

(C) Wrong pitch of blade

(D) Stretching of blade

Ans: D

10. What is the name of the defect due to which the metal chips clog between the teeth of a file?

(A) Glazing of file

(B) Warping of file

(C) Pinning of file

(D) File bite

Ans: C

Also Read: Minimum ITI Passing Marks 2024

11. Why are slots given in a slotted angle plate?

(A) Reducing weight

(B) Job clamping

(C) Better appearance

(D) Easy handling

Ans: B

12. Which type of chisel is used in the cutting of oil grooves?

(A) Diamond point chisel

(B) Flat chisel

(C) Half round nose chisel

(D) Web chisel

Ans: C

13. Which kind of file is used in making the job close to the finishing size?

(A) Double cut file

(B) Second cut file

(C) Single cut file

(D) Curved cut file

Ans: B

14. Name the property of the metal that hinders the tensile forces allowing the metal to stay unruptured.

(A) Malleability

(B) Tenacity

(C) Ductility

(D) Elasticity

Ans: B

15. Which kind of punch is used in the witnessing of marks?

(A) Centre punch

(B) Bell punch

(C) Pin punch

(D) Dot punch

Ans: D

16. Name the calliper that has one leg with adjustable divider point and another leg bent.

(A) Spring joint calliper

(B) Outside calliper

(C) Jenny Calliper

(D) Inside calliper

Ans: D

17. In which part must the weight of the hammer be stamped?

(A) Eye hole

(B) Cheek

(C) Pein

(D) Face

Ans: B

18. Which taper is found on a drill shank?

(A) Jerno taper

(B) Morse taper

(C) Metric taper

(D) Pin taper

Ans: B

19. Which type of hammer is used for riveting?

(A) Straight pein hammer

(B) Cross pein hammer

(C) Ball pein hammer

(D) Sledge hammer

Ans: C

20. Why is a bevel protractor used?

(A) Measuring the depth

(B) Measuring the angle

(C) Setting the workpiece

(D) Checking the length

Ans: B

Also Check: ITI Electrician Mock Test Questions: MCQs For Govt Exam

ITI Fitter Mock Test MCQs for Fitter Theory 2nd Year

21. Which finishing process has very high dimensional accuracy?

(A) Turning

(B) Filing

(C) Lapping

(D) Grinding

Ans: C

22, Why is a slit provided in a lapping tool?

(A) For adjusting the sleeves

(B) For retaining abrasives

(C) For expansion

(D) For clearance

Ans: C

23. What forms the hypotenuse of a triangle while checking with a sine bar?

(A) Slip gauges height

(B) Sine bar length

(C) Sine bar width

(D) Surface plate

Ans: B

24. Why is normalising done?

(A) For removing stress and strain

(B) For increasing wear resistance

(C) For developing high hardness

(D) For adding cutting ability

Ans: A

25. Why is the tempering procedure done on steel?

(A) For regulating the toughness and hardness

(B) For relieving stress and strain

(C) For refining grain structure

(D) For adding cutting ability

Ans: A

26. Which kind of bearing metal has self lubrication?

(A) Cadmium based alloy

(B) Aluminium alloy

(C) Sintered Alloy

(D) White Metal

Ans: C

27. Which kind of bearing is used for taking a higher axial thrust load?

(A) Angular contact ball bearing

(B) self align roller bearing

(C) Tapered roller bearing

(D) Roller bearing

Ans: C

28. Which bearing material is used in the connection of electrical motors and rods?

(A) Copper lead alloy

(B) Sintered alloy

(C) Aluminium alloy

(D) White metal

Ans: A

29. Why are deep grooved ball races provided in a ball bearing?

(A) Carrying journal loads

(B) Withstanding radial loads

(C) Withstanding shock

(D) Withstanding axial thrust

Ans: D

30. Why is a thrust ball bearing used?

(A) For vertical thrust load

(B) For radial thrust load

(C) For radial load

(D) For axial load

Ans: A

Also Read: ITI Seat Allotment 2024: 1st, 2nd, 3rd Round Merit List, Admission Result

31. What is the remedy to a constant dripping household tap despite firm closing?

(A) Tightening the stuffing box

(B) Replacing washer

(C) Replacing the tap

(D) Renewing the tap spindle

Ans: B

32. What is a pipe fitting of 90 degree called whose branches may have equal diameter?

(A) Union joint

(B) Coupling joint

(C) Elbow joint

(D) Tee joint

Ans: D

33. Which kind of pipe joint branches out at 90 degree?

(A) concentric reducer

(B) Eccentric reducer

(C) Tee branch

(D) Coupling

Ans: C

34. Which type of pipe fitting is used in the closing of a pipeline that has an internal thread?

(A) Coupling

(B) Reducer

(C) Cap

(D) Plug

Ans: D

35. What is the name of the plumbing tool that is used in the assembling and dismantling of pipes with a diameter between 50 mm and 150 mm.

(A) Footpoint pipe wrench

(B) Strap wrench

(C) Stillson pipe wrench

(D) Chain pipe wrench

Ans: D

36. Which kind of jig does not have a base plate?

(A) Sandwich jig

(B) Template jig

(C) Plate jig

(D) Table jig

Ans: B

37. Which device is used for holding, locating, and not guiding a cutting tool at the time of machinery operation?

(A) Machine vice

(B) C clamp

(C) fixture

(D) Jig

Ans: C

38. What kind of fixture is used in machining on surfaces that are evenly spaced?

(A) Angle plate fixture

(B) Indexing fixture

(C) Vice jaw fixture

(D) Plate fixture

Ans: B

39. Which device holds, offers support, locates and guides a cutting tool during operation?

(A) Machine vice

(B) Chuck

(C) Fixture

(D) Jig

Ans: D

40. Which part restricts the incorrect loading of components in a jig?

(A) Press fit bush

(B) Locating pin

(C) Clamp

(D) Guide plate

Ans: B

Also Check: List of ITI Courses After 12th 2024: Science, Arts, Commerce Stream

ITI Fitter Exam Pattern

The exam pattern must be known to the candidates who have enrolled in the ITI Fitter trade course. The exam is conducted in 4 semesters. The course has a total duration of two years.

The exam pattern for the ITI Fitter trade can be found in below:

Subject	Number of Questions	Marks Allotted
Fitter Trade Theory	38	76
Workshop Science and Calculation	6	12
Engineering drawing	6	12
Employability Skills	25	50
Total	75	150
